Zelmer ZMW3131W (MW3131) [61/64] Additional information

61MW3131-001_v04

PROGRAMME PRODUCT WEIGHT, VOLUME TIME [s]

A-5 Fish

250 g 3:50

350 g 4:50

450 g 6:20

A-6 Pasta

50 g (in 450 ml of cold water) 17:30

100 g (in 800 ml of cold water) 20:00

A-7 Soup

200 ml 2:00

400 ml 3:10

A-8 Porridge

550 g 8:00

1100 g 12:00

The results of automatic cooking depend on the shape and size of foodstuffs, your cooking

preferences as regards particular products and the arrangement of products inside the

oven. Should you feel that the cooking results could have been better, you may need to

adapt the cooking time to your own needs.

Multi-stage cooking

You can set up to 2 cooking stages. In the case of multi-stage cooking, if defrosting is one

of the cooking stages, the defrosting program will be automatically started as the rst one.

When one stage is nished, a sound signal will be heard and the next stage will start.

Automatic cooking cannot be one of the multi-stage cooking programmes.

EXAMPLE

You want to set defrosting for 5 minutes and then to cook for 7 minutes at the 80%

microwave power. Complete the following steps:

Press the Wt./Time Defrost button twice. The display shows „ ” and and

indicator lights will come on.

Turn the knob in the or direction, in order to set the defrosting time 5:00.

Press the Microwave button The display will show “ ”.

In order to select the microwave power level P80, press the Microwave button again or

turn the knob in the or direction until the display shows “ ”.

Press the Start/+30 s /Conrm button to conrm the microwave power level.

Turn the knob in the or direction, in order to set the cooking time to 7 minutes.

Press the Start/+30 s /Conrm, button to start the cooking. A sound signal will be

heard to indicate the start of the defrosting, the remaining defrosting time will be shown on

the display. The second sound signal will inform you about the start of the cooking. The end

of the multi-stage cooking will be signalled by a ve-time sound.

Additional information

The initial turning of the knob will be signalled by a single sound.

Each started programme can be stopped by pressing the Stop/Clear button. Press the

Start/+30 s /Conrm button to resume the stopped programme. By pressing the Stop/

Clear button twice you will end the programme.

In the case of cooking with the use of Microwave function, press the Microwave

button. The current microwave power level will appear on the display for 3 seconds.

When in the cooking mode, after pressing the Clock/Pre-Set button the display will

show the current time. After 3 seconds the indications will return to the previous state.

If during the operation of the oven the door has been opened, then after its closing

press the Start/+30 s /Conrm button in order to resume the oven operation.

If within one minute after the end of setting, the programme will not be conrmed by

means of the Start/+30 s /Conrm button, the settings will be cancelled. The current time

will appear on the display.

The correct pressing of a button will be signalled by a single sound. In case of incorrect

pressing, no sound will be heard.

The end of programme will be signalled by a ve-time sound.

Ecology – Environmental protection

Each user can contribute to protect the environment. It is neither difcult nor expensive.

In order to do so:

Return cardboard packages to recycling points.

Throw polyethylene (PE) bags into appropriate containers.

Return a worn out appliance to an appropriate collecting point as the

components of the appliance may pose a threat to the environment.

Do not dispose the appliance with the municipal waste!

Delayed start

This function makes it possible to start the oven at a later time, for example, the clock

shows 11:10, you want to start cooking at 11:30.

Set the clock (see the „Setting the clock” section).

Set the cooking programme. Two cooking stages can be set as a maximum.

The defrosting should not be set in the delayed start function.

EXAMPLE: You want to set the cooking for 7 minutes at the 80% power level.

a) Press the Microwave button.

b) Turn the knob in the or direction to set the microwave power level P80.

c) Press the Start/+30 s /Conrm button to conrm the power level.

d) Turn the knob in the or direction to set the cooking time to 7 minutes.

After completing the above steps do not press the Start/+30 s /Conrm button, proceed

as follows:

Press the Clock/Pre-Set button. The hour digits will start ashing.

In order to set the programme starting hour, turn the knob in the or direction

until the display shows “ ” (it is possible to set the digits from 0 to 23).

Press the Clock/Pre-Set button, The minute digits will start ashing.

In order to set the minutes, turn the knob in the or direction until the display

shows “ ” (it is possible to set the digits from 0 to 59).

Press the Start/+30 s /Conrm button to conrm the settings. The display will show

the current time and the icon will ash.

After reaching the set time, a double sound signal will be heard, the set cooking

programme will start.

After the delayed start has been programmed, the current time will be visible

on the display. In order to check the time setting, press the Clock/Pre-Set

button once – the set time will be displayed for 3 seconds. The delayed start

function can be cancelled by simply pressing the Stop/Clear button.

The delayed start function is only active if the current time has been

previously set on the display, otherwise the function will be inactive.

Automatic menu (Auto Menu)

The microwave oven has the automatic menu function, which does not require the cooking

time or microwave power programming. The menu includes several products: pizza,

potatoes, meat, vegetables, sh, pasta, soup, porridge.

Each of the automatic menu programmes has several weight or volume options, for which

duration times have been preset accordingly.

Turn the knob in the direction to select the automatic cooking menu. „ ” will

be shown on the display and the and symbols.

Turn the knob in the direction, the display will show “ ”, “ ”, …, “ ”.

After selecting the programme, conrm it by pressing the Start/+30 s /Conrm button.

Turn the knob in order to set the weight of the food.

Press the Start/+30 s /Conrm button to start the cooking. The remaining cooking time

will be visible on the display.

When the countdown is nished, a ve-time sound signal will be heard. If the clock has

been previously set, the display will show the current time.

EXAMPLE

In order to set the automatic menu for cooking 400 grams of potatoes, complete the

following steps:

Turn the knob in the direction until the display shows “ ”.

Press the Start/+30 s /Conrm button to conrm the automatic menu programme.

Turn the knob in order to set the 400 g weight on the display.

Press the Start/+30 s /Conrm, button to start the cooking.

AUTOMATIC MENU TABLE

PROGRAMME PRODUCT WEIGHT, VOLUME TIME [s]

A-1 Pizza

200 g 2:30

400 g 4:10

A-2 Potatoes

200 g 4:40

400 g 8:40

600 g 10:10

A-3 Meat

250 g 4:10

350 g 5:10

450 g 6:30

A-4 Vegetables

200 g 3:30

300 g 4:20

400 g 5:10

The manufacturer does not accept any liability for any damages resulting from unintended use or

improper handling.

The manufacturer reserves his rights to modify the product any time in order to adjust it to law

regulations, norms, directives, or due to construction, trade, aesthetic or other reasons, without notifying

in advance.
