Shipping conditions
-Remove table before shipping
CAUTION
When transporting outdoors, only transport in shipping vehicles with roofs or sufficient
weather protection.
CAUTION
Protect machine from shipping damage using tie-down straps, packaging materials and
sufficient gaps to other shipped goods.
- Ambient temperature for transport:
Minimum temperature +10 °C (+50 F)
Maximum temperature +40 °C (+104 F)
CAUTION
Handle machine and machine parts with care.
Do not place any heavy loads on top of the machine or machine parts.
Avoid harsh impacts.
Only lift at the specified points.
Take special care in transporting electronic components.
Unloading, inspection and damage reporting
After unloading:
1. Remove shipping packaging.
2. Dispose of packaging according to applicable waste disposal law.
3. Inspect machine and machine parts for shipping damage.
4. Check shipment for completeness.
In case of shipping damage or incomplete shipment:
1. Immediately document the details of the damage.
2. Also note the claim on shipping papers.
3. Photograph the damage.
4. Send report to TROTEC.
Storage conditions
- Store machine and machine parts in a dry area.
- Protect machine and machine parts from scratches.
- Store electronic components especially carefully in a packaged state.
- In case of longer term storage, protect exposed metal parts (e.g. oil the parts).
- Ambient temperature for storage:
Minimum temperature +10 °C (+50 F)
Maximum temperature +40 °C (+104 F)
Storage Location
In storage room or packaged with adequate weather protection.
The storage location must be free of caustic materials, vapors and combustible materials.
