Maintenance plan
daily weekly monthly yearly
Laser
Lens, mirror #4 Check
Cleaning if
required
mirrors #1...3
Check
Cleaning if
required
Processing table and rul-
ers
Cleaning
Entire working area –
general cleaning
Cleaning
Exhaust System
Bag filter
According to the operation manual
of the exhaust system
Filter mat
Particle filter
Activated carbon filter
Cooling System
Pump filter
According to the operation manual
of the exhaust system
Condenser heater
Cooling agent
Pump
For detailed information on the maintenance activities on exhaust and cooling sys-
tems please refer to the respective manuals.
