Workpiece Removal Door
Open door (1) by pulling forward on the
two handles
Remove the workpieces with the broom (2)
The bracket (3) for the broom has 3 magnets
and is mounted on the side of the machine
Door must be closed during
laser operation.
Pass-through opening (optional)
Open the pass-through by folding down door (4)
Insert bypass jumper in socket (5) for pass-
through.
Do not reach into opening
during operation.
Warning of laser radiation
Class 4. Take all necessary
measures (compare section
5.2.2Laser Safety)
