SP 500
Version 2.0 © TROTEC Produktions- u. Vertriebs GmbH
41 / 51
Technical changes reserved Freilingerstraße 99, A-4614 Marchtrenk
www.troteclaser.com
Start of Operation
Enable machine with key (1)
Check whether EMERGENCY-OFF
pushbutton (2) is unlocked
Turn on main switch (3)
Close the top lid. Wait for reference move.
Drive the laser head to its forward-most po-
sition
Key
Clean lens (4), reinstall and secure
Install nozzle (5)
Drive the laser head to reference point by
simultaneously activating these
Keys
