Page 13
Electrical Data
CLH
Models
Power input
at nominal
conditions
per
compressor
(kW)
Current at
nominal
conditions
per
compressor
(A)
Power input
at max.
conditions
per
compressor
(kW)
Current
at max.
conditions
per
compressor
FLA (A)
Start up
current
LRA (A)
Power
factor at
nominal
conditions
Crankcase
heater @
230 V/1Ø
(W)
Unit fuse
size
(A)
Cable
section
(mm
2
)
182
Circuit 1 6 10.1 9 15 99 0.84 70
50 16
Circuit 2 6 10.1 9 15 99 0.84 70
202
Circuit 1 8.5 14.4 12 21 127 0.84 70
63 25
Circuit 2 8.5 14.4 12 21 127 0.84 70
242
Circuit 1 12 20 15 24 150 0.87 65
63 25
Circuit 2 12 20 15 24 150 0.87 65
302
Circuit 1 13.7 24.3 17 29 175 0.81 75
80 35
Circuit 2 13.7 24.3 17 29 175 0.81 75
352
Circuit 1 12.9 21.8 16 28 198 0.84 70
100 35
Circuit 2 15.8 26.7 24 41 225 0.84 120
402
Circuit 1 15.8 26.7 24 41 225 0.84 120
100 35
Circuit 2 15.8 26.7 24 41 225 0.84 120
502
Circuit 1 18.8 31.8 28 48 272 0.84 150
125 50
Circuit 2 18.8 31.8 28 48 272 0.84 150
552
Circuit 1 20.3 34.3 28 48 272 0.84 150
125 70
Circuit 2 25.3 44.2 35 58.5 320 0.83 150
602
Circuit 1 25.3 44.2 35 58.5 320 0.83 150
160 70
Circuit 2 25.3 44.2 35 58.5 320 0.83 150
CLH STD Models 182 202 242 302 352 402 502 552 602
Nominal current input A 22.2 30.6 41.9 51.4 51.3 56.2 66.4 81.3 91.2
Maximum current input A 32.1 43.3 49.9 60.8 71.6 84.8 97.8 108.8 119.8
Nominal power input kW 13.0 18.0 25.0 28.8 30.1 33.0 39.0 47.0 52.0
Maximum power input kW 18.8 25.4 31.0 36.0 42.1 49.9 57.6 64.7 71.8
Starting current (LRA) A 116 150 176 207 256 269 322 370 381
CLH LN Models 182 202 242 302 352 402 502 552 602
Nominal current input A 22.6 31.0 42.3 52.1 52.0 56.9 67.0 82.0 91.9
Maximum current input A 32.5 43.7 50.3 61.5 72.3 85.5 98.5 109.5 120.5
Nominal power input kW 13.4 18.4 25.4 29.5 30.8 33.7 39.7 47.7 52.7
Maximum power input kW 19.3 25.9 31.4 36.7 42.8 50.6 58.3 65.4 72.5
Starting current (LRA) A 116 150 176 207 256 269 323 371 382
CLH ELN Models 182 202 242 302 352 402 502 552 602
Nominal current input A 22.6 31.0 43.5 52.1 52.0 56.9 67.0 82.0 91.9
Maximum current input A 32.5 43.7 51.5 61.5 72.3 85.5 98.5 109.5 120.5
Nominal power input kW 13.4 18.4 26.1 29.5 30.8 33.7 39.7 47.7 52.7
Maximum power input kW 19.3 25.9 32.1 36.7 42.8 50.6 58.3 65.4 72.5
Starting current (LRA) A 116 150 177 207 256 269 323 371 382
CLH HPF Models 182 202 242 302 352 402 502 552 602
Nominal current input A 23.7 32.1 43.4 53.7 53.6 58.5 73.8 83.6 93.5
Maximum current input A 33.6 44.8 51.4 63.1 73.9 87.1 100.1 111.1 122.1
Nominal power input kW 14.0 19.0 26.0 30.3 31.6 34.5 43.5 48.5 53.5
Maximum power input kW 19.8 26.4 32.0 37.5 43.6 51.4 59.1 66.2 73.3
Starting current (LRA) A 118 151 177 209 258 271 325 373 384
Compressors @ 400 V / 3 Ph / 50 Hz
CLH SIF Models 352 402 502 552 602
Nominal current input A 57.5 62.4 77.7 87.5 97.4
Maximum current input A 77.8 91.0 104.0 118.5 133.0
Nominal power input kW 33.9 36.8 45.8 50.8 55.8
Maximum power input kW 45.9 53.7 61.4 68.5 75.6
Starting current (LRA) A 262 275 329 377 391
Units @ 400 V / 3 Ph / 50 Hz
