Page 14
Electrical Data (continued)
Units @ 400 V / 3 Ph / 50 Hz
CLH Models
Units with 1 pump Units with 2 pumps
kW A kW A
182 0.8 1.7 2 x 0.8 2 x 2.1
202 0.8 1.7 2 x 0.8 2 x 2.1
242 1.1 3.1 2 x 1.5 2 x 3.8
302 1.1 3.1 2 x 1.5 2 x 3.8
352 1.5 3.8 2 x 1.8 2 x 4.9
402 1.8 4.9 2 x 1.8 2 x 4.9
502 1.8 4.9 2 x 1.8 2 x 4.9
552 1.8 4.9 2 x 1.8 2 x 4.9
602 1.8 4.9 2 x 1.8 2 x 4.9
CLH STD Models with pump 182 202 242 302 352 402 502 552 602
Nominal current input A 24.3 32.7 45.7 55.2 56.2 61.1 71.3 86.2 96.1
Maximum current input A 34.2 45.4 53.7 64.6 76.5 89.7 102.7 113.7 124.7
Nominal power input kW 13.8 18.8 26.5 30.3 31.9 34.8 40.8 48.8 53.8
Maximum power input kW 19.6 26.2 32.5 37.5 43.9 51.7 59.4 66.5 73.6
Starting current (LRA) A 118 152 180 211 260 274 327 375 386
CLH LN Models with pump 182 202 242 302 352 402 502 552 602
Nominal current input A 24.7 33.1 46.1 55.9 56.9 61.8 71.9 86.9 96.8
Maximum current input A 34.6 45.8 54.1 65.3 77.2 90.4 103.4 114.4 125.4
Nominal power input kW 14.2 19.2 26.9 31.0 32.6 35.5 41.5 49.5 54.5
Maximum power input kW 20.1 26.7 32.9 38.2 44.6 52.4 60.1 67.2 74.3
Starting current (LRA) A 119 152 180 211 261 274 328 376 387
CLH ELN Models with pump 182 202 242 302 352 402 502 552 602
Nominal current input A 24.7 33.1 47.3 55.9 56.9 61.8 71.9 86.9 96.8
Maximum current input A 34.6 45.8 55.3 65.3 77.2 90.4 103.4 114.4 125.4
Nominal power input kW 14.2 19.2 27.6 31.0 32.6 35.5 41.5 49.5 54.5
Maximum power input kW 20.1 26.7 33.6 38.2 44.6 52.4 60.1 67.2 74.3
Starting current (LRA) A 119 152 181 211 261 274 328 376 387
CLH HPF Models with pump 182 202 242 302 352 402 502 552 602
Nominal current input A 25.8 34.2 47.2 57.5 58.5 63.4 78.7 88.5 98.4
Maximum current input A 35.7 46.9 55.2 66.9 78.8 92.0 105.0 116.0 127.0
Nominal power input kW 14.8 19.8 27.5 31.8 33.4 36.3 45.3 50.3 55.3
Maximum power input kW 20.6 27.2 33.5 39.0 45.4 53.2 60.9 68.0 75.1
Starting current (LRA) A 120 153 181 213 263 276 330 378 389
CLH EH Models (Option 0) * 182 202 242 302 352 402 502 552 602
Nominal current input A 58.9 67.3 91.9 101.4 102.4 130.3 140.5 156.8 166.7
Maximum current input A 68.8 80.0 99.9 110.8 122.7 158.9 171.9 187.8 202.3
Nominal power input kW 37.8 42.8 58.5 62.3 63.9 82.8 88.8 97.5 102.5
Maximum power input kW 43.6 50.2 64.5 69.5 75.9 99.7 107.4 115.2 122.3
Starting current (LRA) A 153 186 226 257 307 343 396 446 460
CLH EH Models (Option 1) * 182 202 242 302 352 402 502 552 602
Nominal current input A 70.5 78.9 114.9 124.4 125.4 141.9 152.1 168.4 178.3
Maximum current input A 80.4 91.6 122.9 133.8 145.7 170.5 183.5 199.4 213.9
Nominal power input kW 45.8 50.8 74.5 78.3 79.9 90.8 96.8 105.5 110.5
Maximum power input kW 51.6 58.2 80.5 85.5 91.9 107.7 115.4 123.2 130.3
Starting current (LRA) A 164 198 249 280 330 354 408 457 472
CLH EH Models (Option 2) * 182 202 242 302 352 402 502 552 602
Nominal current input A 93.5 101.9 126.5 136.0 137.0 153.5 163.7 180.0 189.9
Maximum current input A 103.4 114.6 134.5 145.4 157.3 182.1 195.1 211.0 225.5
Nominal power input kW 61.8 66.8 82.5 86.3 87.9 98.8 104.8 113.5 118.5
Maximum power input kW 67.6 74.2 88.5 93.5 99.9 115.7 123.4 131.2 138.3
Starting current (LRA) A 187 221 260 291 341 366 420 469 484
CLH SIF Models with pump 352 402 502 552 602
Nominal current input A 62.4 67.3 82.6 92.4 102.3
Maximum current input A 82.7 95.9 108.9 123.4 137.9
Nominal power input kW 35.7 38.6 47.6 52.6 57.6
Maximum power input kW 47.7 55.5 63.2 70.3 77.4
Starting current (LRA) A 267 280 333 381 396
Pump(s)
* Data given for all versions.
