Physical Data - CLH STD / STD EH
(1) Data based on 7 °C leaving chilled water temperature and 35 °C ambient air temperature.
(2) Data based on 45 °C leaving hot water temperature and 7 °C ambient air temperature.
(3) Maximum power input includes : maximum compressor power input and maximum fan power input.
(4) Sound pressure level values refer to ISO standard 3744.
CLH STD / STD EH sizes 182 202 242 302 352 402 502 552 602
Nominal cooling capacity (1) kW 40.8 54.8 67.3 78.6 87.9 98.7 110.4 120.9 131.4
Compressor power input - Cooling kW 12.5 17.5 24.6 28.0 33.6 35.0 42.0 49.4 56.7
Maximum power input (3) kW 18.8 25.4 31.0 36.0 42.1 49.9 57.6 64.7 71.8
EER 3.3 3.1 2.7 2.8 2.6 2.8 2.6 2.4 2.3
Nominal heating capacity (2) kW 45.7 58.0 77.4 90.4 101.0 113.5 127.0 139.7 152.4
Compressor power input - Heating kW 10.9 17.2 25.1 29.0 31.6 35.3 41.3 47.5 53.6
Number of refrigerant circuits 2 2 2 2 2 2 2 2 2
Capacity steps % 50/100 50/100 50/100 50/100 43-57/100 50/100 50/100 43-57/100 50/100
REFRIGERANT
Type
HFC 407C
Charge kg 7 11 13 14.5 15 17 20 22 24
COMPRESSORS
Number 2 2 2 2 2 2 2 2 2
Type
Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll
EVAPORATORS
Number 2 2 2 2 2 2 2 2 2
Type
Plate Plate Plate Plate Plate Plate Plate Plate Plate
Antifreeze heater power input W 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35
AIR COOLED CONDENSERS
Number 2 2 2 2 2 2 2 2 2
Total face area per coil
m
2
2.1 2.1 2.1 2.85 3.6 3.6 3.6 3.6 3.6
Number of rows 2 3 4 3 3 4 4 5 5
FANS
Number 2 2 2 3 3 3 3 3 3
Total air flow
m
3
/h 21000 21000 21000 31700 32400 32100 32100 32100 32100
Power input
kW 0.96 0.96 0.96 1.44 1.44 1.44 1.44 1.44 1.44
WATER CONNECTIONS
Type
Male gas threaded
Inlet diameter inch 2" 2" 2" 2" 2" 2" 2" 2" 2"
Outlet diameter inch 2" 2" 2" 2" 2" 2" 2" 2" 2"
DIMENSIONS
Length
mm 2110 2110 2110 2760 3110 3110 3110 3110 3110
Width mm 1110 1110 1110 1110 1110 1110 1110 1110 1110
Height mm 1750 1750 1750 1750 1750 1750 1750 1750 1750
WEIGHT
Basic - Shipping / Operating kg 640 / 650 690 / 700 850 / 860 900 / 910 1000 / 1010 1150 / 1160 1150 / 1160 1285 / 1295 1320 / 1330
1 pump - Shipping / Operating kg 672 / 682 722 / 732 882 / 892 932 / 942 1032 / 1042 1182 / 1192 1182 / 1192 1317 / 1327 1352 / 1362
2 pumps - Shipping / Operating kg 692 / 702 742 / 752 902 / 912 952 / 962 1052 / 1062 1202 / 1212 1202 / 1212 1337 / 1347 1372 / 1382
Water tank+1 pump - Shipping / Operating
kg 737 / 947 787 / 997 947 / 1157 1032 / 1362 1152 / 1552 1302 / 1702 1302 / 1702 1437 / 1837 1472 / 1872
Water tank+2 pumps - Shipping / Operating
kg 757 / 967 807 / 1017 967 / 1177 1052 / 1382 1172 / 1572 1322 / 1722 1322 / 1722 1457 / 1857 1492 / 1892
SOUND LEVELS
Sound power levels dB(A) 86 86 87 87 89 91 91 95 95
Sound pressure levels at 10 meters (4) dB(A) 54 54 55 55 57 59 59 63 63
