Physical Data - CLH ELN / ELN EH
CLH ELN / ELN EH sizes 182 202 242 302 352 402 502 552 602
Nominal cooling capacity (1) kW 40.8 54.1 64.5 71.4 87.0 93.0 104.2 120.9 131.4
Compressor power input - Cooling kW 12.3 18.2 25.9 31.8 33.9 39.4 47.0 49.4 56.7
Maximum power input (3) kW 19.3 25.9 31.4 36.0 42.8 50.6 58.3 65.4 72.5
EER 3.3 3.0 2.5 2.2 2.6 2.4 2.2 2.4 2.3
Nominal heating capacity (2) kW 40.4 54.8 74.2 82.0 100.0 106.0 122.0 139.7 152.4
Compressor power input - Heating kW 12.6 17.2 25.0 28.8 31.6 35.2 41.2 47.5 53.6
Number of refrigerant circuits 2 2 2 2 2 2 2 2 2
Capacity steps % 50/100 50/100 50/100 50/100 43-57/100 50/100 50/100 43-57/100 50/100
REFRIGERANT
Type
HFC 407C
Charge kg 9 12 15 15 15 17 20 22 24
COMPRESSORS
Number 2 2 2 2 2 2 2 2 2
Type
Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll
EVAPORATORS
Number 2 2 2 2 2 2 2 2 2
Type
Plate Plate Plate Plate Plate Plate Plate Plate Plate
Antifreeze heater power input W 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35 2 x 35
AIR COOLED CONDENSERS
Number 2 2 2 2 2 2 2 2 2
Total face area per coil
m
2
2.1 2.1 2.85 2.85 3.6 3.6 3.6 3.6 3.6
Number of rows 3 4 4 4 4 4 4 5 5
FANS
Number 2 2 3 (2xEH) 3 (2xEH) 3 (2xEH) 3 3 3 3
Total air flow
m
3
/h 15000 14250 14250 14250 11250 24000 24000 23500 23500
Power input
kW 1.4 1.4 2.1(1.4x EH) 2.1(1.4xEH) 2.1(1.4xEH) 2.1 2.1 2.1 2.1
WATER CONNECTIONS
Type
Male gas threaded
Inlet diameter inch 2" 2" 2" 2" 2" 2" 2" 2" 2"
Outlet diameter inch 2" 2" 2" 2" 2" 2" 2" 2" 2"
DIMENSIONS
Length
mm 2100 2100 2760 2760 3110 3110 3110 3110 3110
Width mm 1110 1110 1110 1110 1110 1110 1110 1110 1110
Height mm 1850 1850 1850 1850 1850 1850 1850 1850 1850
WEIGHT
Basic - Shipping / Operating kg 660 / 670 710 / 720 900 / 910 950 / 960 1120 / 1130 1170 / 1180 1170 / 1180 1305 / 1315 1340 / 1350
1 pump - Shipping / Operating kg 692 / 702 742 / 752 932 / 942 982 / 992 1152 / 1162 1202 / 1212 1202 / 1212 1337 / 1347 1372 / 1382
2 pumps - Shipping / Operating kg 712 / 722 762 / 772 952 / 962 1002 / 1012 1172 / 1182 1222 / 1232 1222 / 1232 1357 / 1367 1392 / 1402
Water tank+1 pump - Shipping / Operating
kg 757 / 967 807 / 1017 1032 / 1362 1082 / 1412 1272 / 1672 1322 / 1436 1322 / 1722 1457 / 1857 1492 / 1892
Water tank+2 pumps - Shipping / Operating
kg 777 / 987 827 / 1037 1052 / 1382 1102 / 1432 1292 / 1692 1342 / 1742 1342 / 1742 1477 / 1877 1512 / 1912
SOUND LEVELS
Sound power levels dB(A) 78 78 79 80 81.5 83 83 83 83
Sound pressure levels at 10 meters (4) dB(A) 46 46 47 48 49.5 51 51 51 51
(1) Data based on 7 °C leaving chilled water temperature and 35 °C ambient air temperature.
(2) Data based on 45 °C leaving hot water temperature and 7 °C ambient air temperature.
(3) Maximum power input includes : maximum compressor power input and maximum fan power input.
(4) Sound pressure level values refer to ISO standard 3744.
