Operating Limits
CLH
182 202 242 302
Min. Max. Min. Max. Min. Max. Min. Max.
Chiller
Liquid outlet
temperature
Water °C +6 to +15
Brine (for low liquid temperature
application)
°C -8 to +5
Temperature difference K 3 to 7
Flow rate l/h 3902 9106 6731 15705 8268 19296 9656 22532
Max. operating pressure - Water side
bar 10
Ambient air
Air entering
temperature
Cooling - STD °C 15 46 15 46 15 46 15 46
Cooling - LN/HPF °C 15 46 15 46 15 46 15 46
Cooling - ELN °C -18 42 -18 42 -18 42 -18 42
Heating °C -5 to +15 °C
External static
pressure
Standard fans Pa 0
High pressure fans - HPF version Pa 80
Heat pump °C +30 to +50
Recommended system chilled water volume
litres 200 280 330 370
Nominal supply voltage 400 V / 3 Ph / 50 Hz (nominal)
CLH
352 402 502 552 602
Min. Max. Min. Max. Min. Max. Min Max Min. Max.
Chiller
Liquid outlet
temperature
Water °C +6 to +15
Brine (for low liquid temperature
application)
°C -8 to +5
Temperature difference K 3 to 7
Flow rate l/h 10800 25198 12126 28294 13563 31648 12997 37668 14126 37668
Max. operating pressure - Water side
bar 10
Ambient air
Air entering
temperature
Cooling - STD °C 15 46 15 46 15 46 15 44 15 44
Cooling - LN/HPF °C 15 46 15 46 15 46 15 44 15 44
Cooling - ELN °C -18 42 -18 42 -18 42 -18 42 -18 42
Cooling - SIF °C -18 48 -18 48 -18 48 -18 48 -18 48
Heating °C -5 to +15 °C
External static
pressure
Standard fans Pa 0
High pressure fans - HPF version Pa 80
High pressure fans - SIF version Pa 150
Heat pump °C +30 to +50
Recommended system chilled water volume
litres 450 530 600 677 747
Nominal supply voltage 400 V / 3 Ph / 50 Hz (nominal)
CLH 182 to 302
CLH 352 to 602
