Page 23
Dimensions (continued)
(+35 mm only for transport)
2" male
VIEW CVIEW B
368
1100
470 404
2" male
501
784 470
VIEW C
Models CLH 242 ELN and CLH 302 to 602 STD/LN/ELN/HPF
Unit with water tank
Unit without water tank
Models Versions
Dimensions
A (mm)
Dimensions
B (mm)
Dimensions
C (mm)
Number of
fans
CLH 242 ELN 2406 2760 1850 3
CLH 302
Standard 2406 2760 1750 3
LN/HPF 2406 2760 1850 3
ELN 2406 2760 1850 3
CLH
352 to
602
Standard 2756 3110 1750 3
LN/HPF 2756 3110 1850 3
ELN 2756 3110 1850 3
35 mm
only for
transport
VIEW A
Lifting point
Cable entry
Lifting point
177 177
36.5 36.51037
1110
