Page 25
Space Requirements
Single unit applications
Multi units applications
1000 mm
3000 mm
1000 mm
1000 mm
1500 mm
VIEW A
WALL A
WALL A
1.5 m
1.5 m
A1
A1 A3A2
A2
2.0 m
1.0 m
1.0 m
WALL C
ARRANGEMENT 1 ARRANGEMENT 2
WALL C
WALL D
WALL D
WALL B
WALL B
LOUVRED A & C
SOLID B & D
SOLID A & B
SOLID C & D
SOLID A & C
LOUVRED B & D
LOUVRED A & B
SOLID C & D
LOUVRED A & D
SOLID B & C
A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3 A1 A2 A3
ARRANGEMENT 1 1.0 1.0 1.0 1.0 0.8 0.8 1.0 0.8 0.8 1.0
ARRANGEMENT 2 1.0 1.5 1.0 1.0 2.0 1.0 0.8 2.0 0.8 1.0 1.5 0.8 0.8 1.5 1.0
Note : No more than one wall can be higher than the unit.
The area enclosed by the wall must be kept clear of all obstructions that would impede air flow to the unit.
