TD-W8950ND 150Mbps Wireless Lite N ADSL2+ Modem Router User Guide

4.5.7.1 Default Gateway

Choose “Routing→Default Gateway” menu, you can configure the Default Gateway routing in the

next screen as shown in Figure 4-59.

Figure 4-59

¾ Enable Automatic Assigned Default Gateway - Select this checkbox, and then the Router will

accept the first received default gateway assignment from one of the PPPoA, PPPoE or

MER/DHCP enabled PVC(s). If this checkbox is not selected, you have to enter the static

default gateway and/or an interface. Click Save/Apply to save your configurations.

)

Note:

If changing the Enable Automatic Assigned Default Gateway from unselected to selected, you

must reboot the Router to get the automatic assigned default gateway.

4.5.7.2 Static Route

Choose “Routing→Static Route” menu, you can view and add the Static Route entry in the next

screen as shown in Figure 4-60. A static route is a pre-determined path that network information

must travel to reach a specific host or network.

Figure 4-60

To add a new entry, follow the steps below.

1. Click the Add button in Figure 4-60 to go to the Static Route Add page as shown in Figure

4-61.

2. Enter the IP address of the destination network. This parameter specifies the IP network

address of the final destination.

3. Enter the Subnet Mask for the destination.

4. Select the Use Gateway IP Address checkbox and enter the IP address of the gateway. The

gateway is an immediate neighbor of your ADSL Router that will forward the packet to the

destination. On the LAN, the gateway must be a router on the same segment as your Router;

over Internet (WAN), the gateway must be the IP address of one of the remote nodes.
