TD-W8151N 150Mbps Wireless N ADSL2+ Modem Router User Guide

• SSID: Wireless network name shared among all points in a wireless network. The SSID

must be identical for all devices in the wireless network. It is case-sensitive and must not

exceed 32 characters (use any of the characters on the keyboard). Make sure this setting

is the same for all stations in your wireless network. Type the desired SSID in the space

provided.

• Authentication Type: Select an authentication type from the drop-down list, which

allows you to configure security features of the wireless LAN interface. Options available

are: Disabled, WEP-64Bits, WEP-128Bits, WPA-PSK, WPA2-PSK, and WPA-PSK/

WPA2-PSK.

¾ WDS Settings: Select On/Off to enable/disable WDS. With this function enabled, the Router

can bridge two or more WLANs.

• MAC Address: Enter the MAC Address you wish to bridge in the field.

¾ Wireless MAC Address Filter: Wireless access can be filtered by using the MAC addresses

of the wireless devices transmitting within your network’s RADIUS.

• Active: If you wish to filter users by MAC Address, select “Activated”, and “Deactived” for

don’t.

• Action: To filter wireless users by MAC Address, select “Allow Association” or “Deny

Association” the follow Wireless LAN station(s) association.

• MAC Address: Enter the MAC Address you wish to filter in the field.

4.4 Advanced Setup

Choose “Advanced Setup”, you can see the next submenus:

Figure 4-22

Click any of them, and you will be able to configure the corresponding function.

4.4.1 Firewall

Choose “Advanced Setup→Firewall” menu, and you will see the next screen (shown in Figure

4-23).

Figure 4-23
