-90-

Key-In:

protocol is used in the corresponding IPsec Proposal. The

inbound key here must match the outbound ESP

encryption key at the other end of the tunnel, and vice

versa.

Outgoing SPI:

Specify the Outgoing SPI (Security Parameter Index)

manually. The Outgoing SPI here must match the

Incoming SPI value at the other end of the tunnel, and

vice versa.

AH Authentication

Key-Out:

Specify the outbound AH Authentication Key manually if

AH protocol is used in the corresponding IPsec Proposal.

The outbound key here must match the inbound AH

authentication key at the other end of the tunnel, and vice

versa.

ESP Authentication

Key-Out:

Specify the outbound ESP Authentication Key manually if

ESP protocol is used in the corresponding IPsec

Proposal. The outbound key here must match the inbound

ESP authentication key at the other end of the tunnel, and

vice versa.

ESP Encryption

Key-Out:

Specify the outbound ESP Encryption Key manually if

ESP protocol is used in the corresponding IPsec

Proposal. The outbound key here must match the inbound

ESP encryption key at the other end of the tunnel, and

vice versa.

¾ List of IPsec Policy IPsec

In this table, you can view the information of IPsec policies and edit them by the action buttons.

The first entry in

Figure 3-60 indicates: this is an IPsec tunnel, the local subnet is 192.168.0.0/24,

the remote subnet is 192.168.3.0/24 and this tunnel is using IKE automatic negotiation. It is

enabled.

Tips:

● 0.0.0.0.0/32 indicates all IP addresses.

● Refer to Appendix Troubleshooting 5 for the configuration of subnet.
