-51-

Status:

Activate or inactivate the entry.

Note:

● The External port and Internal Port should be set in the range of 1-65535.

● The external ports of different entries should be different, whereas the internal ports can be the

same.

¾ List of Rules

In this table, you can view the information of the entries and edit them by the Action buttons.

The first entry in Figure 3-32 indicates: This is a Virtual Server entry named host1, all the TCP data

packets from Internet to port 65534-65535 of the Router will be redirected to the port 65534-65535 of

the LAN host with IP address of 192.168.0.103, and this entry is activated.

3.3.1.5 Port Triggering

Some applications require multiple connections, such as Internet games, video conferencing, Internet

calling, P2P download and so on. Port Triggering is used for those applications requiring multiple

connections.

When an application initiates a connection to the trigger port, all the ports corresponding to the

incoming port will open for follow-up connections.

Choose the menu Advanced→NAT→Port Triggering to load the following page.

Figure 3-33 Port Triggering

The following items are displayed on this screen:
