-34-

Choose the menu Network→DMZ→DMZ to load the following page.

Figure 3-18 DMZ

The following items are displayed on this screen:

¾ DMZ

Status:

Activate or inactivate this entry. The DMZ port

functions as a normal LAN port when it’s disabled.

Mode:

Select the mode for DMZ port to control the connection

way among DMZ, LAN and Internet. Options include:

Public and Private.

IP Address:

Enter the IP address of DMZ port.

Subnet Mask:

Enter the Subnet Mask of DMZ port.

Tips:

The DHCP service, DHCP Client and DHCP Reservation functions are available when the DMZ port is

enabled. For the configuration instructions, please refer to section 3.1.4.1 to.3.1.4.4.

Note:

When the DMZ port is enabled in Public Mode, please do not enable the DHCP service of DMZ port if

your ISP provides a single public IP address. Otherwise, the Hosts in DMZ will be unable to access

Internet normally. If an IP address range is provided by your ISP, please configure the DHCP pool

based on the IP address range.

3.1.6 MAC Address

The MAC (Media Access Control) address, as the unique identifier of the router in network, does not

need to be changed commonly.
