Fluke 725 ex [13/54] Dc voltage measurement

Multifunction Process Calibrator

Specifications

All specifications apply from +18 °C to +28 °C unless stated otherwise. All specifications

assume a five-minute warmup period.

DC Voltage Measurement

Range Resolution

Accuracy,

(% of Reading + Counts)

30 V (upper display) 0.001 V 0.02 % + 2

10 V (lower display) 0.001 V 0.02 % + 2

90 mV 0.01 mV 0.02 % + 2

Temperature coefficient -10 °C to 18 °C, +28 °C to 55 °C: ±0.005 % of range per °C

DC Voltage Source

Range Resolution

Accuracy,

(% of Reading + Counts)

100 mV 0.01 mV 0.02 % + 2

10 V 0.001 V 0.02 % + 2

Temperature coefficient -10 °C to 18 °C, +28 °C to 55 °C: ±0.005 % of range per °C

Maximum load: 1 mA

Millivolt Measurement and Source*

Range Resolution Accuracy

-10 mV to 75 mV 0.01 mV ±(0.025 % + 1 count)

Maximum input voltage: 30 V

Temperature coefficient -10 °C to 18 °C, +28 °C to 55 °C: ±0.005 % of range per °C

*Select this function by pressing T. The signal is available at the thermocouple miniplug connector.

DC mA Measurement and Source

Range Resolution

Accuracy,

(% of Reading + Counts)

24 mA 0.001 mA 0.02 % + 2

Temperature coefficient -10 °C to 18 °C, +28 °C to 55 °C: ±0.005 % of range per °C

Drive capability: 250 Ω at 20 mA
