Multifunction Process Calibrator
Performance Tests
15
Lower Display Voltage Measurement Tests
1. Press RESET on the 5520A.
2. Press V on the UUT until MEASURE and V appear on the lower display.
3. Make the connections shown in Figure 3.
4. Set up the 5520A to output each of the voltages in Table 6 and verify that the UUT
readings are within the limits shown.
5. Press STBY on the 5520A.
Table 6. Lower Display Voltage Readings
5520A Outputs UTT Readings
0.000 V -0.002 V to +0.002 V
10.000 V 9.996 V to 10.004 V
5.000 V 4.997 V to 5.003 V
