729/729 FC
Calibration Manual
6
Product Models
Model
psi Range,
Resolution
bar Range,
Resolution
kPa Range,
Resolution
Comment
729 30G
-12.0000 psi to
+30.0000 psi
-0.82737 bar to
+2.06842 bar
-82.737 kPa to
+206.843 kPa
No wireless
communication
729 150G
-12.000 psi to
+150.000 psi
-0.8273 bar to
+10.3421 bar
-82.73 kPa to
+1034.21 kPa
729 300G
-12.000 psi to
+300.000 psi
-0.8273 bar to
+20.6843 bar
-82.73 kPa to
+2068.43 kPa
729 30G FC
-12.0000 psi to
+30.0000 psi
-0.82737 bar to
+2.06842 bar
-82.737 kPa to
+206.843 kPa
Wireless
communication
for Fluke Connect
729 150G FC
-12.000 psi to
+150.000 psi
-0.8273 bar to
+10.3421 bar
-82.73 kPa to
+1034.21 kPa
729 300G FC
-12.000 psi to
+300.000 psi
-0.8273 bar to
+20.6843 bar
-82.73 kPa to
+2068.43 kPa
729CN 200K
-12.0000 psi to
+30.0000 psi
-0.82737 bar to
+2.06842 bar
-82.737 kPa to
+206.843 kPa
For China, no
wireless
communication
729CN 1M
-12.000 psi to
+150.000 psi
-0.8273 bar to
+10.3421 bar
-82.73 kPa to
+1034.21 kPa
729CN 2M
-12.000 psi to
+300.000 psi
-0.8273 bar to
+20.6843 bar
-82.73 kPa to
+2068.43 kPa
729CN 200K FC
-12.0000 psi to
+30.0000 psi
-0.82737 bar to
+2.06842 bar
-82.737 kPa to
+206.843 kPa
For China,
wireless
communication
for Fluke Connect
729CN 1M FC
-12.000 psi to
+150.000 psi
-0.8273 bar to
+10.3421 bar
-82.73 kPa to
+1034.21 kPa
729CN 2M FC
-12.000 psi to
+300.000 psi
-0.8273 bar to
+20.6843 bar
-82.73 kPa to
+2068.43 kPa
729JP 200K N/A N/A
-82.737 kPa to
+206.843 kPa
For Japan, no
wireless
communication
729JP 1M N/A N/A
-82.73 kPa to
+1034.21 kPa
For Japan, 1 MPa
range, no wireless
communication
729JP 2M N/A N/A
-82.73 kPa to
+2068.43 kPa
For Japan, 2 MPa
range, no wireless
communication
729JP 200K FC N/A N/A
-82.737 kPa to
+206.843 kPa
For Japan,
wireless
communication
for Fluke Connect
729JP 1M FC N/A N/A
-82.73 kPa to
+1034.21 kPa
729JP 2M FC
N/A N/A -82.73 kPa to
+2068.43 kPa
