729/729 FC
Calibration Manual
4
Symbols
The symbols used in this manual and on the Product are in Table 1.
Table 1. Symbols
Symbol Description
W
WARNING. RISK OF DANGER.
X
WARNING. HAZARDOUS VOLTAGE. Risk of electric shock.
f
Pressure
Consult user documentation.
Conforms to relevant South Korean EMC Standards.
P
Conforms to European Union directives.
)
Certified by CSA Group to North American safety standards.
Certified by TÜV SÜD Product Service.
Conforms to the Appliance Efficiency Regulation (California Code of Regulations, Title 20,
Sections 1601 through 1608), for small battery charging systems.
This product contains a Lithium-ion battery. Do not mix with solid waste stream. Spent
batteries should be disposed of by a qualified recycler or hazardous materials handler per
local regulations. Contact your authorized Fluke Service Center for recycling information.
China metrology certification mark for measuring instruments manufactured in the Peoples
Republic of China (PRC).
Conforms to relevant Australian Safety and EMC standards.
~
This product complies with the WEEE Directive marking requirements. The affixed label
indicates that you must not discard this electrical/electronic product in domestic household
waste. Product Category: With reference to the equipment types in the WEEE Directive
Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation"
product. Do not dispose of this product as unsorted municipal waste.
