Automatic Pressure Calibrators
Calibration Adjustment
27
Use the test procedure in Table 13 to adjust the voltage input.
Table 13. Voltage Input Adjustment Procedure
Expected Manual Process
(Front Panel)
Expected Electronic Calibration Process
(Remote)
Connect the Product VDC input with Fluke
5522A NORMAL output
Message prompts the operator
Connect VDC input to 5522A NORMAL output
Output 0 V from Fluke 5522A, input actual value
and push Go On to proceed
Output 0 V dc from 5522A
Wait for at least 3 seconds for signal stable
Send command CAL_NEXT <actual_volts> to
proceed
Output 30 V from Fluke 5522A, input actual
value and push Go On to proceed
Output 30 V dc from 5522A
Wait for at least 3 seconds for signal stable
Send command CAL_NEXT <actual_volts> to
proceed
Adjust mA Input
The test equipment to adjust the mA input is listed in Table 14.
Table 14. Required Test Equipment for mA Input Adjustment
Equipment Minimum Specifications Recommended Model
DC Calibrator
DC Voltage: 0 V to 30 V
Accuracy: ±0.002 % +0.5 mV
DC Current 0 mA to 24 mA
Accuracy: ±0.002 % +0.5 μA
Fluke 5522A Multi-Product
Calibrator
Digital Multimeter
DC Current: 0 mA to 26 mA
Accuracy: ±0.002 % +0.5 μA
Fluke 8508A
Note
All reference (actual) values that you input during the calibration
procedure should be the reading from 8508A.
