Automatic Pressure Calibrators
Performance Verification Tests
11
Table 3. Pressure Verification Points (cont.)
Input Pressure
(psi)
12 Month
Lower Limit
12 Month
Upper Limit
729 150G/729FC 150G
-12.000 -12.030 -11.970
-9.000 -9.030 -8.970
-6.000 -6.030 -5.970
-3.000 -3.030 -2.970
0.000 -0.030 0.030
30.000 29.970 30.030
60.000 59.970 60.030
90.000 89.970 90.030
120.000 119.970 120.030
150.000 149.970 150.030
120.000 119.970 120.030
90.000 89.970 90.030
60.000 59.970 60.030
30.000 29.970 30.030
0.000 -0.030 0.030
-3.000 -3.030 -2.970
-6.000 -6.030 -5.970
-9.000 -9.030 -8.970
-12.000 -12.030 -11.970
