729/729 FC
Calibration Manual
8
Korea (KCC) .......................... Class A Equipment (Industrial Broadcasting &
Communication Equipment)
Class A: Equipment meets requirements for
industrial electromagnetic wave equipment and
the seller or user should take notice of it. This
equipment is intended for use in business
environments and not to be used in homes.
USA (FCC) ............................ 47 CFR 15 subpart B. This product is considered
an exempt device per clause 15.103 (non FC
versions only)
Radio Certification ................. (Contains) FCC ID: T68-FBLE, IC: 6627A-FBLE
Frequency ............................. 2402 MHz to 2480 MHz
Output Power ........................ <100 mW
Performance Verification Tests
Fluke recommends re-certification each year. To re-certify, do the verification
procedure. If test points are out of tolerance, calibrate the Product and then re-
verify.
Use the subsequent tests to make sure that the Product is inside its specification
limits.
Verification Equipment
The equipment necessary for verification of the Product is shown in Table 2. If
these instruments are not available, you can replace them with other source and
measure instruments that have the same the minimum specification
requirements.
Table 2. Equipment Required for Verification and Calibration Adjustment
Equipment Minimum Specifications Recommended Model
DC Calibrator
DC Voltage: 0 V to 30 V
Accuracy: ±0.002 % +0.5 mV
DC Current 0 mA to 24 mA
Accuracy: ±0.002 % +0.5 μA
Fluke 5522A Multi-Product Calibrator
Digital Multimeter
DC Current: 0 mA to 26 mA
Accuracy: ±0.002 % +0.5 μA
Fluke 8508A
Pressure
Controller/Calibrator
-14 psi to 300 psi
Accuracy: 0.005 %
Ruska 7252xi
RTD adapter Fluke 720URTDA
