DES-3550 Fast Ethernet Layer 2 Switch

Figure 7- 29. SNMP View Table window

To delete an existing SNMP View Table entry, click the

in the Delete column corresponding to the entry you wish to

delete. To create a new entry, click the Add button and a separate window will appear.

Figure 7- 30. SNMP View Table Configuration window

The SNMP Group created with this table maps SNMP users (identified in the SNMP User Table) to the views created in

the previous window.

The following parameters can set:

Parameter Description

View Name

Type an alphanumeric string of up to 32 characters. This is used to identify the new

SNMP view being created.

Subtree OID

Type the Object Identifier (OID) Subtree for the view. The OID identifies an object tree

(MIB tree) that will be included or excluded from access by an SNMP manager.

View Type

Select Included to include this object in the list of objects that an SNMP manager can

access. Select Excluded to exclude this object from the list of objects that an SNMP

manager can access.

142
