DES-3550 Fast Ethernet Layer 2 Switch

SNMP Host Table

Use the SNMP Host Table window to set up SNMP trap recipients.

Open the SNMP Manager folder, located in the Security Management folder and click on the SNMP Host Table link.

This will open the SNMP Host Table window, as shown below.

To delete an existing SNMP Host Table entry, click the corresponding

under the Delete heading.

To display the current settings for an existing SNMP Group Table entry, click the blue link for the entry under the Host IP

Address heading.

Figure 7- 35. SNMP Host Table window

To add a new entry to the Switch's SNMP Host Table, click the Add button in the upper left-hand corner of the window.

This will open the SNMP Host Table Configuration window, as shown below.

Figure 7- 36. SNMP Host Table Configuration window

The following parameters can set:

Parameter Description

Host IP Address

Type the IP address of the remote management station that will serve as the SNMP

host for the Switch.

SNMP Version

V1 - To specifies that SNMP version 1 will be used.

V2 - To specify that SNMP version 2 will be used.

V3-NoAuth-NoPriv - To specify that the SNMP version 3 will be used, with a

NoAuth-NoPriv security level.

V3-Auth-NoPriv - To specify that the SNMP version 3 will be used, with an Auth-

NoPriv security level.

V3-Auth-Priv - To specify that the SNMP version 3 will be used, with an Auth-Priv

security level.

Community String or

SNMP V3 User Name

Type in the community string or SNMP V3 user name as appropriate.

To implement your new settings, click Apply. To return to the SNMP Host Table, click the Show All SNMP Host Table

Entries link.

146
