DES-3550 Fast Ethernet Layer 2 Switch
The information on this window is described as follows:
Parameter Description
Auth PAE State
The Authenticator PAE State value can be: Initialize, Disconnected, Connecting,
Authenticating, Authenticated, Aborting, Held, Force_Auth, Force_Unauth, or N/A.
N/A (Not Available) indicates that the port's authenticator capability is disabled.
Backend State
The Backend Authentication State can be Request, Response, Success, Fail, Time-
out, Idle, Initialize, or N/A. N/A (Not Available) indicates that the port's authenticator
capability is disabled.
Port Status
Controlled Port Status can be Authorized, Unauthorized, or N/A.
171
