6.4 Installation versions

6.4.1 Installing additional sensor protection pipes

With the SBP 700, further sensor protection pipes can be installed.

For this installation, proceed as follows:

»Observe the markings on the top and bottom of the cylinder

casing.

»Saw with a hole cutter at the required marking on the cylinder

casing (recommended hole cutter Ø 70 mm).

»Drill carefully through the cylinder casing into the thermal

insulation. The drilling depth is limited by the extent to which

the connector penetrates the insulation.

»Remove the remaining insulation from around the connector.

»Undo the cap and ﬁt the sensor protection pipe.

6.4.2 Installing the BGC immersion heater

The immersion heater is used for electric booster heating.

—With the SBP 200 | 400 the immersion heater can be mounted

on the r.h. or l.h. side.

—One or two immersion heaters can be mounted with the

SBP 700.

»Remove the cap from the connector.

»Undo the vent plug with an SW 32 socket spanner.

BGC installation in a SBP E | SBP E cool

26_03_01_0228

BGC installation in a SBP 700 E | SBP 700 E SOL

26_03_01_0227

7. Commissioning

7.1 Commissioning

Commissioning must only be carried out by a heating

contractor.

»Fill and vent the appliance.

»Check the functions of the special accessories in accordance with

the operating and installation instructions supplied with them.

»Check the function of the on-site safety valve.

7.2 Decommissioning

If the heating system is not in operation and the installation

location is not protected against frost, drain the appliance and

connected system. This is relevant where there is a risk of frost.

8. Maintenance

No special maintenance is required for the appliance. A regular

visual check is sufﬁcient.
