Automatic Voltage Regulation Icon:IndicatesthattheACinputiseitherlow

orhighandthattheAVRfunctionisactivelyboostingorcuttingtheline.The

AVRiconisalsousedinconjunctionwiththeEVENTSicontoindicateAVR

events.

EXTERNAL BATTERY Icon (Select Models):DisplayedonlywhentheEXTERNAL

BATTERYSETTINGCONTROLisactive.

BATTERY CAPACITY Icon:Usedtobetterdescribethebatterycapacitybar

graph.

Basic Operation continued

Display Power Conditions

Usethe button to advance through power conditions.

1.VoltageIn 2.VoltageOut 3. Estimated Runtime

(in minutes)

4.Load%

5.LoadWattage* 6.KWH/Day** 7.BatteryCapacity%

* Load Wattage is displayed in watts up to “999”, and then will be displayed in Kilowatts.

** The Kilowatt Hour usage per day reports daily power consumption of equipment connected to the UPS in

KWH in a 24-hour cycle. Press and hold the

button for 4 seconds to reset the accumulator to “0”.

Note: When the UPS is in Battery Mode (power is supplied to the output from the batteries), the BATTERY icon

will be lit in the display instead of the AC INPUT icon.
