Tripplite SMART PRO SMX1000XLRT2U Черный [16/96] Basic operation

IEC 320-C13

IEC 320-C19

Basic Operation continued

Other UPS Features (Rear Panel)

AC Outlets: AllmodelsincludeIEC320-C13outlets.Selectmodelsalso

includeIEC320-C19outlets.Theseoutletsprovideyourconnectedequipment

with AC line power during normal operation and battery power during blackouts

andbrownouts.TheUPSprotectsequipmentconnectedtotheseoutletsagainst

damagingsurgesandlinenoise.IfyouhaveaserialorUSBconnectiontoyour

UPS,youcanremotelyrebootconnectedequipmentbyturningtheoutletsOFF

andONusingTrippLite’sPowerAlertSoftware.Theoutletsaredividedintoone

ormoreloadbanks(labelled“LOAD1,”etc.)whichmayberemotelyswitched

OFFandONwithoutinterruptingpowertoequipmentconnectedtotheother

outlets.Outletslabelled“UNSWITCHED”maynotberemotelyswitchedoff.

Communications Ports (USB or RS-232): TheseportsconnectyourUPSto

anyworkstationorserver.UsewithTrippLite’sPowerAlertSoftwareandincluded

cables to enable your computer to automatically save open files and shut down

equipmentduringablackout.AlsousePowerAlertSoftwaretomonitorawide

varietyofAClinepowerandUPSoperatingconditions.ConsultyourPowerAlert

Software manual or contact Tripp Lite Customer Support for more information.

See“USBandRS-232SerialCommunications”inthe“OptionalInstallation”

section for installation instructions.

EPO (Emergency Power Off) Port: YourUPSfeaturesaEPOportthatmaybe

usedtoconnecttheUPStoacontactclosureswitchtoenableemergency

invertershutdown.SeeOptionalInstallation.

Accessory Slot: Remove the small cover panel from this slot to install optional

accessoriestoremotelymonitorandcontrolyourUPS.Refertoyouraccessory’s

manual for installation instructions. Contact Tripp Lite Customer Support at www.

tripplite.com/supportformoreinformation,includingalistofavailableSNMP,

network management and connectivity products.

External Battery Connector (optional on select models): Usetoconnect

TrippLiteexternalbatterypacksforadditionalruntime.Refertoinstructions

available with the battery pack for complete connection information and safety

warnings.Visitwww.tripplite.com/support/battery/index.cfmtolocatethe

supportedbatterytype(s)foryourUPS.

Output Breaker (select models): YourUPSfeaturesoneormorebreakersthat

protectyourUPSfromoutputoverload.Ifoneormorebreakerstrip,remove

some of the load on the circuit(s), then reset them by pressing the breaker

switch(es) in.
