plus). We recommend, however, to replace both sets at

the same time (2 pcs. item No. 06732). We recommend

to replace all membranes at the same time for pumps

with several outlets.

Attention! By all means pull mains plug before

opening the air pump!

Membrane replacement:

The membranes can be replaced quickly and easily. You

can remove the upper part of the casing after you have re-

moved the 4 casing screws at the bottom of the air pump.

For sera air 110 plus (fig. 7):

The membrane can be pulled out of the holder bracket

upwards as an entire block. Remove the black plate

from the membrane and place it on the same opening

of the replacement membrane. The pump will not func-

tion without this plate! Therefore, the plate must not be

disposed of along with the old membrane. Then push

the new membrane back into the holder bracket. The

hose connector must fit exactly into the cut-outs in the

casing parts and must not be pushed in with force.

Then screw the casing back together.

For sera air 275 R plus / 550 R plus (fig. 8.1 – 8.2):

First loosen the 3 holder screws of the double mem-

brane/s (fig. 8.1). The membranes can be taken out up-

wards after having removed the screws and the small

white holder(s) (fig. 8.2). The air hoses on the mem-

branes now must be disconnected from the connection

pieces, the membrane blocks are then free and can be

replaced with new ones. The hoses are first pushed

back onto the connection pieces and then fastened

with the screws and the holder(s). Then screw the cas-

ing back together.

Advice for minimizing noise:

The sera air plus air pump was developed according to

newest physical findings, and is equipped with a partic-

ularly thick walled and sound-absorbing casing.

However, operation noise may be audible even under

optimal conditions, especially in quiet rooms (sleeping

rooms) at night.

Every air pump produces audible vibration and hum

noise. However, these are minimized by providing

some counter pressure. Therefore also use a safety

valve. A hose clamp or a regulator valve that reduce air-

flow will considerably reduce the noise level.

You can roughly adjust the air output by a hose clamp

also with adjustable pumps. The counter pressure pro-

vided that way will also increase the life span of the

membranes.

Unsuitable locations often cause higher noise levels due

to resonance vibrations. In that case place the mem-

brane pump in another location.

Technical Data:

AC 220 – 240 V ~ 50/60 Hz

Due to technical reasons the electronic adjustment

range of the sera air R plus air pumps does not begin

from < 1 l/h (0.3 US gal./h) but from considerably high-

er flow rates.

Within this context, the produced pressure describes

the water depth into which the sera air plus (free hose

end provided!) pumps down [approx. 1.2 m (4 ft.)]. Hose

length far above 3 m (10 ft.), non-return valves, air-

stones, Y connectors etc. may considerably reduce this

performance. Damaged, worn-out or dirty membranes

will also decrease performance.

Connecting two or more pump outlets via the supplied

Y connectors (applies only for sera air 275 R plus and

550 R plus, fig. 9) may considerably increase the

achieved pump depth.

Do not submerge

sera air 110 plus (item No. 08812)

sera air 275 R plus (item No. 08814)

sera air 550 R plus (item No. 08816)

sera air 110 plus sera air 275 R plus sera air 550 R plus

l/h (US gal./h) [equiva-

lent to approx. l/min (US

gal./ min)]:

min. 110 (29)

[approx. 1.8 l/min

(0.5 US gal./min)]

min. 275 (73)

[approx. 4.5 l/min

(1.2 US gal./min)]

min. 550 (145)

[9.2 l/min (2.4 US

gal./min)]

Watts: 3 4 8

Produced pressure: ≥0.010 mPa (≥100 mbar) ≥0.014 mPa (≥140 mbar) ≥0.014 mPa (≥140 mbar)

Connectors: 1 2 4

Spare membrane(s).

(item No. per complete

replacement kit)

06730 06732 06732 (2 pcs.)

Air filter (item No.) 08819 08819 08819

Recommended accesso-

ry (item No.)

sera air set “S”

08813

sera air set “M”

08815

sera air set pond “L”

08817

IPX4
