xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide

372

Figure 8-66 NetBIOS Filtering Settings window

The fields that can be configured are described below:

Parameter Description

Unit

Select the unit you want to configure. (EI and SI Mode Only)

NetBIOS Filtering Ports

Select the appropriate port to include in the NetBIOS filtering configuration.

Extensive NetBIOS

Filtering Ports

Select the appropriate port to include in the Extensive NetBIOS filtering

configuration. Extensive NetBIOS is NetBIOS over 802.3. The Switch will deny the

NetBIOS over 802.3 frame on these enabled ports.

Ports

Tick the appropriate ports to be configured.

Click the Select All button to select all ports in each individual section.

Click the Clear All button to deselect all ports in each individual section.

Click the Apply button to accept the changes made for each individual section.

Traffic Segmentation Settings

Traffic segmentation is used to limit traffic flow from a single or group of ports, to a group of ports. This method of

segmenting the flow of traffic is similar to using VLANs to limit traffic, but is more restrictive. It provides a method of

directing traffic that does not increase the overhead of the master switch CPU.

To view this window, click Security > Traffic Segmentation Settings as shown below:
