(1) Main Menu
This menu displays the ON/OFF status of the power supply and information on signals input to the projector.
.
DVI Rate(Hz) Pixel H Pixel V Link
1 60.00 2048 2400 Dual
2
3 60.00 2048 2400 Dual
4
Power
Signal Status
Warning Status
Temperature
10h59m
Light Source Time Hide
Exhaust
30.3 deg.C
Intake
30.3 deg.C
Inside
30.3 deg.C
ON OFF
ONOFF
PROJECTION None
Main
Setting
Convergence
Lens
Option
Logout
host PJ-1
user: root
License
MEMO
0
When the power of this unit is off (main power is on), the “Main”, “Image”, “Setting”, “Convergence”, “Lens” and
“Option” menus will be grayed out and will not be selectable.
Item Setting Value Description
Power ON
OFF
Turns on/off the LD block.
ON :
Turns on the LD block.
OFF : Turns off the LD block.
MEMO
0
The
following
operating modes of the projector are displayed to the
right of the “OFF” button.
STANDBY : Standby (OFF)
PROJECTION : LD block illuminated (ON)
FAN ENABLE : FAN Enable (OFF " ON)
DEVICE ENABLE : Elemental Device Enable (OFF " ON)
COOLING : Cooling (OFF)
EMERGENCY : Error Occurred (Cooling not performed)
EMERGENCY COOLING : Error Occurred (Cooling performed)
0
When in the standby mode, clicking the “ON” button each time
switches the mode in the sequence of “STANDBY” " “DEVICE
ENABLE” " “FAN ENABLE” " “PROJECTION”.
0
Clicking the “OFF” button when the power is on switches the
projector to the cooling mode. The power of the projector cannot
be turned on during the cooling process (10 seconds).
35
Operation and Settings
