R indicates the factory default.
Item Setting Value Description
E-Mail Setting
For configuring the e-mail feature.
E-Mail
ON
R OFF
ON : Use the mail feature.
OFF :
Do not use the mail feature.
E-Mail Sender -
(Default
Value:
lower 3
bytes of the MAC
address)
For specifying the destination e-mail address of this projector.
E-Mail Address -
(Default Value:
user@localhost)
For specifying the destination e-mail address.
MEMO
0
Specify an address up to a maximum of 64 characters.
0
Make
use
of single-byte alphanumeric characters and “-”“.”“_”“@”.
SMTP Server
Address
-
(Default Value:
1.1.1.1)
For specifying the address of the outgoing mail server (SMTP).
MEMO
0
Specify an address up to a maximum of 15 characters.
0
Make use of numbers and “.”.
E-Mail Auth.
ON
R OFF
ON : Enable the e-mail authentication feature.
OFF :
Disable the e-mail authentication feature.
Auth. Type R PLAIN
LOGIN
CRAM-MD5
For configuring the e-mail authentication type.
PLAIN
:
Set e-mail authentication to “PLAIN”.
LOGIN : Set e-mail authentication to “LOGIN”.
CRAM-MD5 : Set e-mail authentication to “CRAM-MD5”.
Auth. User Account - For configuring the account name during e-mail authentication.
MEMO
0
Specify an address up to a maximum of 31 characters.
0
Make use of single-byte alphanumeric characters and “-”.
Auth. Password - For configuring the password during e-mail authentication.
MEMO
0
Specify an address up to a maximum of 31 characters.
0
Make use of single-byte alphanumeric characters and “-”.
Port No. R 25
465
587
For configuring the SMTP server port number when using the e-mail
authentication feature.
Set - The details of the configuration will be saved.
Test Mail - When the “SEND” button is clicked, the test mail with the contents
configured in the “E-Mail Setting” will be sent.
46
Operation and Settings
