Optional Items
Projection lens
GL-MS4015SZ
0
1.50:1 to 1.84:1 1.22x zoom lens (80" to 300")
GL-MS4016SZ
0
1.50:1 to 1.84:1 1.22x zoom lens (50" to 210")
GL-MS4021SZ
0
2.15:1 to 3.65:1 1.69x zoom lens (80" to 300")
GL-MS4011S
0
1:1.1 short focal length lens (50" to 250")
Replacement filter/sponge (front)
LC43010-003A (Filter)
LC43030-003A (Sponge)
Replacement sponge (right/left side)
LC43030-002A
J3K-0072-00
*1
D-ILA is the abbreviation for Direct Drive Image Light Amplifier.
*2
D-ILA devices are manufactured using extremely high-precision technology with a pixel effectiveness of 99.99%.
Only 0.01% or less of the pixels are either missing or would remain permanently lit.
*3 HDCP is the abbreviation for High-bandwidth Digital Content Protection system. Images from the DVI input
terminal may not be displayed due to HDCP specification changes.
0
The open source software is embedded in this product. For more information, please go to:
http://www3.jvckenwood.com/english/download/lnx/07jvc-pj/
0
Design and specifications are subject to change without prior notice.
0
Please
note
that some of the pictures and illustrations may have been abridged, enlarged or contextualized in order
to aid comprehension. Images may differ from the actual product.
61
