8
The upper half of the window displays the running status of Pharos Control. The lower half contains
corresponding operation buttons. For details, refer to the following table:
Server Status Displays the status of Pharos Control.
Running: Pharos Control is running normally and you can use it to manage devices.
Stopped: Pharos Control is stopped.
Server Port Displays the current server port of Pharos Control.
Open Web Page Click this button to open the management interface with a web browser.
Session
Information
Displays the information of the Client Hosts connecting to Pharos Control, including
Username, Role and Client Address. You can right-click a client and choose to
disconnect it.
Restart Server Click this button to restart Pharos Control.
Stop Server Click this button to stop Pharos Control.
Start Server Click this button to start Pharos Control.
Back up
Database
Click this button to back up the current database and save it as a backup file on your
local computer. If needed, you can restore the database with this backup file.
Restore
Database
Click this button to restore the database with a previous backup file.
Reset Database Click this button to reset the database.
View Logs Click this button and you will be directed to a file folder. Open the txt file in this folder
and you can view the server logs.
Settings Click this button and the following window will pop up. You can change the port
setting and select whether Pharos Control will run automatically upon booting up.
Exit Click this button to exit Pharos Control.
Note:
Do not exit Pharos Control while managing and monitoring devices.
Launch on Linux System
For Linux system, use the command sudo /etc/init.d/pharoscontrol start to launch Pharos Control
server. You can also use the following commands to execute other operations:
sudo /etc/init.d/pharoscontrol shutdown Exit Pharos Control server.
sudo /etc/init.d/pharoscontrol stop Force a shutdown of Pharos Control server.
