Tp-Link TL-WPA7510 KIT V1 [11/39] How can i do that
![Tp-Link TL-WPA7510 KIT V1 [11/39] How can i do that](/views2/1469525/page11/bgb.png)
9
Chapter 2
Initial Use
the top floor. So I bought a new powerline extender to extend
the wireless network.
1. Plug the new powerline extender into a wall socket near one
of the existing powerline extender.
New Powerline Extender
TL-WPA7510
Existing Powerline Device
(For demonstration only)
Powerline
1000Mbps
1000Mbps
2. Check the new extender’s Powerline LED . Is it on?
• If it is on, follow Step 4 > A.
• If it is off, follow Step 3 and Step 4 > B.
3. Join the new powerline extender into the existing powerline
network by pairing two powerline devices.
a . Press the Pair button on the existing powerline device for
1 second. The Power LED starts blinking.
Note: If the Power LED does not blink, press again.
b . Within two minutes, press the Pair button on the new
powerline extender for 1 second. The Power LED starts
blinking. When the Powerline LED turns solid, the pairing
process is complete.
within 2 minutes
Existing
Powerline Device
New Powerline Extender
TL-WPA7510
Blinking
1000Mbps
PairLED
Wi-Fi
Reset
On
Blinking
1000Mbps
PairLED
Wi-Fi
Reset
4. Relocate the new extender to the Wi-Fi “dead” zone.
Note: A red Powerline LED indicates poor signal strength. Move the extender to
another location.
How can I
do that?
