Tp-Link TL-WPA7510 KIT V1 [21/39] Led schedules
![Tp-Link TL-WPA7510 KIT V1 [21/39] Led schedules](/views2/1469525/page21/bg15.png)
19
Chapter 3
Conguring via Web Management Interface
3. Now you can view the detailed information, including device name, IP address, MAC
address, connected wireless band as well as security option.
Tips: You can also see the wireless details by clicking the wireless clients icon on Status> Wireless
Clients.
3. 6. LED Schedules
Automatically turn off LEDs at times when I do not want light in
my room.
For example, I want to turn LEDs off everyday from 00:00am to
7:00am.
1. Connect to the powerline extender wirelessly. Visit http://
tplinkplc.net and log in with the username and password you
set.
2. Go to Device Settings > LED Schedules.
3. Toggle On to enable the LED Scheduler.
Note: Please make sure that the system time is correct before using this
function.
4. Click Add to add an entry.
5. Choose LED Off Time from 00:00 to 7:00, and then check all
boxes from Sunday to Saturday.
6. Click Enable this entry to make it effective.
I want to:
How can I
do that?
