29
Chapter 3
Conguring via Web Management Interface
3. Select the correct End date and time when daylight saving time ends at your local
time zone.
4. Click Save.
3. 11. 3. Upgrade the Firmware
TP-LINK is dedicated to improving and richening the product features, giving you
a better network experience. We will release the latest firmware at TP-LINK official
website, you can download the latest firmware file from our website: www.tp-link.com
and upgrade the firmware to the latest version.
To upgrade the firmware online:
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
2. If there’s any firmware update available for your powerline extender, the update
icon
will display on the top-right corner of the page. Click the icon to go to the
Firmware Upgrade page.
Alternatively, you can go to System Tools > Firmware Upgrade page and click Check
for Upgrade to see if there’s any new firmware.
3. Focus on the Online Upgrade section, and click Upgrade.
4. Wait a few moments for the upgrading and rebooting.
Note:
1. Before upgrading the firmware, it’s better to back up your current settings.
2. During the upgrading process, do not turn off or reset the extender.
To upgrade the firmware manually:
1. Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
