Tp-Link TL-WPA7510 KIT V1 [18/39] Wireless network
![Tp-Link TL-WPA7510 KIT V1 [18/39] Wireless network](/views2/1469525/page18/bg12.png)
16
Chapter 3
Conguring via Web Management Interface
WPSWAN LAN
Wireless Router
WPS
7. Within two minutes, press the Wi-Fi button on the side panel
of the extender. The 2.4GHz and 5GHz LEDs start blinking.
1000Mbps
PairLED
Wi-Fi
Reset
When the corresponding Wi-Fi LED blinks quickly for 3 seconds
and then stays on. It’s done!
3. 5. Wireless Network
3. 5. 1. Customize Wireless Settings
The powerline extender’s wireless network name (SSID) and password, and security
option are preset in the factory. The preset SSID and password can be found on the
product label and Wi-Fi Info Card. You can customize the wireless settings according
to your needs.
Connect to the powerline extender wirelessly. Visit http://tplinkplc.net, and log in with
the username and password you set for the extender.
Go to Wireless > Settings page.
To enable or disable the wireless function:
Select the box to enable the wireless Radio of 2.4GHz or 5GHz. Deselect the box to
disable wireless function. If disabled, all wireless settings will be ineffective.
Done!
