Tp-Link TL-WPA7510 KIT V1 [6/39] 2 physical interface
![Tp-Link TL-WPA7510 KIT V1 [6/39] 2 physical interface](/views2/1469525/page6/bg6.png)
4
Chapter 1
Get to Know Your Powerline Extender
Name Status Indication
Wireless 2.4GHz
On The 2.4GHz wireless band is enabled.
Off The 2.4GHz wireless band is disabled.
Flashing
Slowly: The powerline extender is cloning 2.4GHz
wireless network settings from the main router.
Quickly: The powerline extender is syncing 2.4GHz
wireless network settings from an existing powerline
extender.
Wireless 5GHz
On The 5GHz wireless band is enabled.
Off The 5GHz wireless band is disabled.
Flashing
Slowly: The powerline extender is cloning 5GHz wireless
network settings from the main router.
Quickly: The powerline extender is syncing 5GHz
wireless network settings from an existing powerline
extender.
1. 2. 2. Physical Interface
Ethernet Port
Reset Button
Wi-Fi Button
LED Button
Plug
Pair Button
