Tektronix MSO64 — настройка поиска событий на шине LIN и I3C [333/628]
![Tektronix MSO64 [333/628] Lin serial bus search configuration menu](/views2/1470488/page333/bg14d.png)
Mark On = Stop. The following table lists the fields available when Mark On is set to Stop.
Stop field Description and menu fields
Stop Sets the search to mark Stop events. A Stop event is the I3C Bus condition of a Low to High
transition on the SDA line while the SCL line remains High.
There are no menu fields or controls displayed when this item is selected.
Mark On = HDR Restart. The following table lists the fields available when Mark On is set to HDR Restart.
HDR Restart field Description and menu fields
HDR Restart Sets the search to mark HDR Restart events. An event occurs when an HDR Restart pattern is
sent on the bus.
There are no menu fields or controls displayed when this item is selected.
Mark On = HDR Exit. The following table lists the fields available when Mark On is set to HDR Exit.
HDR Exit field Description and menu fields
HDR Exit Sets the search to mark HDR Exit events. An event occurs when an HDR Exit pattern is sent
on the bus.
There are no menu fields or controls displayed when this item is selected.
LIN serial bus search configuration menu
Use the LIN Search configuration menu to define conditions to search for and mark on an LIN bus waveform. You can have
multiple searches on the same bus.
NOTE. Requires option SRAUTO.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the LIN bus that you want to search.
Mark On Select the type of information for which to search.
Identifier Sets the identifier pattern for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Identifier or Identifier & Data.
Data Bytes Sets the number of data bytes for which to search (one to four bytes). Use the A knob to
change the value.
Only available when Mark On = Data or Identifier & Data.
Menus and dialog boxes
4/5/6 Series MSO Help 303
