Field or control Description
Sample Rate Changes Affect Tap to allow changes to the Sample Rate to affect either the Horizontal Scale or the Record
Length.
Only available when Horizontal Mode = Manual.
Sample Rate Tap to set the Sample Rate using the assigned multipurpose knob, double-tap to set the rate
using the virtual keypad, or tap the up and down arrows. This keeps the oscilloscope at the
specified sample rate regardless of the horizontal or record length settings. This limits the
available horizontal scale settings to those that can be used with the specified sample rate.
Only available when Horizontal Mode = Manual.
Record Length Tap to set the Record Length using the assigned multipurpose knob, double-tap to set the
length using the virtual keypad, or tap the up and down arrows.
Only available when Horizontal Mode = Manual.
Mask Badge configuration menu
Use the Mask Badge configuration menu to set the total number of eye diagram mask hits needed to fail the mask test.
To open the Mask Badge configuration menu, double-tap a Mask badge in the Results column.
Mask Badge configuration menu fields and controls
Field or control Description
Total Sets the total number of hits needed to fail an eye mask test.
Math configuration menu overview
Math waveforms are created by combining and/or mathematically transforming source waveforms into a new waveform for
analysis. Use this menu to create math waveforms (basic or advanced) or add an FFT (Fast Fourier Transform) waveform to the
screen.
To access a Math configuration menu, double-tap a Math waveform badge on the Settings bar. If no Math badge is present, tap
the Add New Math button to add a Math waveform and open the configuration menu.
Use the following links to access information on the Math waveform menus and settings.
Math configuration menu on page 351
Equation Editor (Math configuration menu) on page 354
Add Filter menu (math Equation Editor) on page 356
Add Variable menu (math Equation Editor) on page 356
Menus and dialog boxes
350 4/5/6 Series MSO Help
