User’s Guide for RP7000 Series Active Probe 19

① Solder-in single-ended probe head (RP7-0203).

② 0.2mm Nickel Wire (RP7-0306).

When the points to be tested are widely spaced, the length of the nickel wire

will be increased. At this point, overshoot and ringing will occurs and the

high-frequency response will changes.

To Replace Probe Accessories

1. To replace the probe head

Take care not to damage the connecting part to avoid affecting the probe

performance when replacing the probe head.

Replacing Method:

① Disconnect the current probe head from the active probe amplifier.

② Push the new probe head into the active probe amplifier straightly.

When single-ended probe head is used, pay attention to their

polarities.

2. Replace the probe tip

The probe tip and probe head are connected with screw thread, so please

note the screw rotation and strength when removing and installing the

probe tip.

3. Replace the single-ended ground collar

Make sure the single-ended ground collar is firmly connected to the

copper pipe to ensure the probe performance when replacing it.
