User’s Guide for RP7000 Series Active Probe 21
To Adjust Offset Voltage
RIGOL DS6000/MSO4000/DS4000 series oscilloscope can provide offset
voltage to the RP7000 series active probe. The offset voltage adjusts the
measured signal which exceeds the input dynamic range of the probe within an
appropriate range to ensure the measured signal’s integrity.
You can adjust the offset voltage by operating the front panel menu of the
oscilloscope and the operation method is as shown below.
1. Connect the RP7000 series active probe to the channel input terminal
(such as CH1) of the DS6000/MSO4000/DS4000 oscilloscope, referring to
To Connect to the Oscilloscope.
2. Open the probe offset voltage control menu of the
DS6000/MSO4000/DS4000 oscilloscope (front panel operation: CH1
Probe Bias Voltage) and rotate the knob to adjust the value.
