RIGOL
User’s Guide for RP7000 Series Active Probe 3
General Inspection
1. Inspect the shipping container for damage.
If your shipping container appears to be damaged, keep the shipping
container or cushioning material until you have inspected the contents of
the shipment for completeness and have checked the probe electrically
and mechanically.
If your probe has damaged during shipping, please contact your shipper
and carrier for compensation. RIGOL will provide no free repair or
replacement.
2. Inspect the probe.
If there is any mechanical damage or defect, or if the probe does not pass
electrical and mechanical tests, please contact your RIGOL sales
representative.
3. Check the Accessories.
Please check the accessories according to Accessories and Options in
this guide. If the accessories are incomplete or damaged, please contact
your RIGOL sales representative.
