RIGOL
II User’s Guide for RP7000 Series Active Probe
Safety Terms and Symbols
Terms in this Manual. The following terms may appear in this manual:
WARNING
Warning statements indicate the conditions or practices that could
result in injuries or loss of life.
CAUTION
Caution statements indicate the conditions or practices that could
result in damage to this product or loss of data.
Terms on the Product. The following terms may appear on the product:
DANGER indicates a hazard may immediately happen.
WARNING indicates potential hazard may happen.
CAUTION indicates damage to the instrument or other devices connected to
the instrument may happen.
Symbols on the Product. The following symbols may appear on the product:
High
Voltage
Safety
Warning
Protective
Earth
terminal
Chassis
Ground
Test
Ground
