12 User’s Guide for RP7000 Series Active Probe
To Use RP7000 Series Active Probe
During the use of RP7000 series active probe, correct operations can ensure the
probe performance, prolong the service life of the probe and ensure the
effectiveness of the signal measurement result. This chapter introduces in
detail the using method of the RP7000 series active probe.
Main Topics:
To Connect to the Oscilloscope
To Use the Probe Head
To Replace Probe Accessories
To Adjust Offset Voltage
To Calibrate the Probe
