2 User’s Guide for RP7000 Series Active Probe

Probe Introduction

RP7000, with more than 1.5GHz bandwidth, is an active probe solution for high

frequency application. It can be used to measure differential and single-ended

signals with better common mode rejection. RP7000 uses plug-on socket probe

head and supports 4 types of interchangeable probe heads to optimize the

performance and usability. Besides, its replaceable probe tip prolongs the

service life of the probe and the probe tip spacing can be precisely adjusted to

fit different test point spacing.

RP7000 is compatible with the auto-identification port of RIGOL

DS6000/MSO4000/DS4000 series oscilloscope and can be recognized and

configured automatically by this port. Its snap-in BNC connector enables easier

connection with the oscilloscope.

RP7000 provides various accessories and options and multiple replaceable

components which make it applicable to be used in different tests and

measurements.
