Insulation Testers
Safety Information
3
• Remove test leads from the Tester before opening the Tester case or battery door. Never operate the
Tester with the cover removed or the battery door open.
• Comply with local and national safety requirements when working in hazardous locations.
• Use proper protective equipment, as required by local or national authorities when working in
hazardous areas.
• Avoid working alone.
• Use only the replacement fuse specified or the protection may be impaired.
• Check the test leads for continuity before use. Do not use if the readings are high or noisy.
Table 1. Symbols
B AC (Alternating Current) J Earth Ground
F DC (Direct Current) I Fuse
X WARNING: risk of electric shock T Double Insulated
b Battery (Low battery when shown on display) W Important information; see manual
